Combination High-Efficiency Air Filter

Our company specializes in selling combination high-efficiency air filters, with high-quality galvanized frames, aluminum alloy frames, and plastic frames. The filtering material of the combination high-efficiency air filters is made of glass fiber or synthetic fiber. The combination high-efficiency air filters we provide are all produced using materials that meet international standards. Materials can be selected according to customer requirements to customize specifications, suitable for terminal filtration of air conditioning units and various high-volume air purification equipment in industries such as pharmaceuticals, electronics, food, hospitals, cosmetics, semiconductors, precision machinery, and automobiles.

Material selection:

The outer frame is made of high-quality galvanized steel plate or plastic frame, and the filter material is made of extremely fine fiberglass.

Product features:
1. Large dust holding capacity.
2. Low resistance and high air volume.
3. The product is easy to install.
4. Suitable for terminal filtration of air conditioning units and various high-volume air purification equipment in industries such as pharmaceuticals, electronics, food, hospitals, cosmetics, semiconductors, precision machinery, and automobiles.

Composition materials and operating conditions:

Frame material Aluminum profiles
Seals Polyurethane glue
Separators Hot melt adhesives
Filter media Fiberglass filter paper
Use the highest temperature 80℃
Use the highest humidity 80%
Seals Ethyl acetate


Model size and other parameters:

Model Dimensions
(mm)
Rated air volume
(m³/h)
Initial Resistance
(Pa)
Efficiency (colorimetric) Filter
ZZH-10SS 295×595×295 1000  ≤250 ≥99.9 4
ZZH-15SS 595×595×295 1500  ≤250 ≥99.9 6
ZZH-21SS 595×595×295 2100  ≤250 ≥99.9 8
ZZH-27SS 595×595×295 2700  ≤250 ≥99.9 10
ZZH-33SS 610×610×295 3300  ≤250 ≥99.9 12
