CJBS Concave Cover Single Bag Filter

CJBS concave cover single bag filter adopts a clever concave cover structure design. The liquid enters the filter cylinder from the side and then fills the filter bag. The liquid flows out from the outlet. The installation of the filter bag adopts a pressure ring structure, which is economical and practical.
Advantage:
1. Good sealing: there will be no external leakage problems, and there will also be no side leakage problems;
2. Low pressure loss;
3. Simple and convenient operation;
4. Economical and affordable.

PREV：CITF Turtle Back Single Bag Filter NEXT：CJMF-K Quick Opening Multi-Bag Filter

Model Description

Technical Parameter Table

Technical Parameter Table

Filter model	CJBS-0101-BB10	CJBS-0102-BB10	CJBS-0104-BB10
Filter bag specifications	Size 01	Size 02	Size 04
Filtration area	0.25㎡	0.5㎡	0.14㎡
Standard flow rate m³/h	20	36	11
Design pressure bar	10	10	10
Design temperature °C	160	160	160
Material	SS304, SS361, 2205, HC22, PP, lined PTFE
Sealing ring material	Nitrile rubber, EPDM, fluorine rubber, tetra fluoro fluorine
Surface treatment	Shot peening, pickling passivation, polishing, wire drawing
Volume (L)	13	27	5
Weight (Kg)	29	33	16

Parameters

Filtration area: 0.5㎡
Standard flow rate m³/h: 36
Design pressure bar: 10
Design temperature °C: 160
